This multimeter is designed to safely and accurately troubleshoot a variety of automotive and household eletrical problems,it is provided with a LCD display for clear reading,it can be used to measure DC/AC voltage/current ,resistance,capacitance,frequency,duty cycle,diode,continuity and live wire.



Max display value:6000

LCD display with backlight for clear reading.

Can measures AC/DC voltage/current,resistance,capacitance,frequency,duty cycle,diode,continuity and live wire.

VFC test and NCV test with warning alarm function.

Includes True RMS,data hold and low battery indication functions.

Auto power off in 15mins if there's no operation.

Built-in LED flashlight,convenient to use at night or dark environment.

With overload protection on all ranges.

Equipped with a back bracket for supporting multimeter,and also can collect test probe for your convenience.

Protected by rubber for drop protection.

Great for troubleshooting automotive and household electrical problems.



Maximum Display:6000

Range Control:Auto Range

DC Voltage:60mV/600mV/6V/60V/600V

AC Voltage:60mV/600mV/6V/60V/600V

V.F.C Range:200V~600V

DC Current:600uA/6000uA/60mA/600mA/10A

AC Current:600uA/6000uA/60mA/600mA/10A

Resistance:600ohm/6Kohm/60Kohm/600Kohm/6Mohm/60Mohm

Capacitance:9.999nF/99.99nF/999.9nF/9.999uF/99.99uF/999.9uF/9.999mF/99.99mF

Frequency(HzVGrade):99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz/99.99MHz

V/A Frequency Range:10Hz-10kHz

Duty Cycle:10%~95%

Overload Protection:DC/AC 250V(True RMS)

Diode Test:YES

Continuity Buzzer:Yes

Auto Power Off: about 15mins

Sampling Rate:0.4s

Altitude:2000m

Power Supply:3*1.5V AAA Batteries(NOT Included)

Operating Temperature:0~40C(32~104F),45~80% relative humidity

Storage Temperature:-20~60C(-4~140F),45~80% relative humidity



1x digital multimeter

1x pair of test leads

1x user manual
